HEM Saw Semi-Automatic
Band Saws

Mitering and non-mitering semi-auto band saws

If you are in the market for a mitering or non-mitering semi-automatic horizontal, vertical or dual column band saw, then you should consider a HEM Saw. Made in Pryor, Oklahoma, the HEM Saw name is synonymous with quality, service and support.

Along with the best service and support you also get a performance powerhouse. HEM Saw band saws cut harder and straighter than any other saw on the market.

Mitering Horizontal Features

  • 60 degree single miter
  • 1″ – 1.5″ blade sizes
  • Flood and mist coolant
  • Dual feed rate
  • Over 15 customizable options

Dual Column Features

  • 1.25″ – 3.125″ blade sizes
  • Flood and mist coolant
  • Dual feed rate
  • Full hydraulics
  • Fully customizable

Vertical Features

  • 60 degree single miter
  • 1″ – 2″ blade sizes
  • Flood and mist coolant
  • Left & right miter
  • Dual feed rate
  • Fully customizable

Service & Support

Enjoy service and support like no other saw manufacturer can provide. HEM Saw has 11 service technicians strategically placed throughout the US to provide customers with timely and knowledgeable service. That’s 10 more service technicians than the closest competitor.

No saw manufacturer comes close to offering the parts inventory that HEM Saw offers. HEM Saw is still stocking parts for saws that are more than 30 years old.

A PROVEN PERFORMANCE POWERHOUSE

Product Photos

Header 1 P-50 P-65 P-90 P-110 P-140
Punch
Hole Size (max. material)
Max. Hole Size (material)
50 Tons
1-1/16" (3/4")
5" (1/8")
60 Tons
1-1/16" (3/4")
5" (1/8")
90 Tons
1-1/8" (1")
5" (3/16")
110 Tons
1-7/16" (1")
5" (1/4")
140 Tons
1-3/4" (1")
5" (5/16")
Plate Shear


* w/ fixed hold down
15-1/2" Long
3/4" x 10"
5/8" x 15"
15-1/2" Long
3/4" x 10"
5/8" x 15"
18" Long
1" x 8"
3/4" x 12"
1/2" x 18"
20-1/2" Long
1" x 12"
3/4" x 18"
1/2" x 20"
20-1/2" Long
1" x 14"
3/4" x 18"
1/2" x 20"
Angle Shear
** w/ special blade
5" x 5" x 3/8"
4" x 4" x 1/2"
5" x 5" x 3/8"
4" x 4" x 1/2"
5" x 5" x 1/2" 6" x 6" x 5/8" 6" x 6" x 5/8"
Bar Shear
Round (min. to max.)
Square (min. to max.)

1/4" to 1-1/2"
1/2" to 1"

1/4" to 1-1/2"
1/2" to 1"

1/2" to 2"
1/2" to 1-3/8"

1/2" to 2"
1/2" to 1-3/8"

1/2" to 2"
1/2" to 1-3/8"
Copper Notcher (tons)
(max.)
56
2-3/4" x 4" x 1/4"
56
2-3/4" x 4" x 1/4"
75
3-1/2" x 5" x 3/8"
75
3-1/2" x 5" x 3/8"
75
3-1/2" x 5" x 3/8"
Motor Std. 230/460 3 ph.
1800 RPM
Opt. Phase & Voltage
Available
7.5 HP 3 PH. 7.5 HP 3 PH. 10 HP 3 PH. 10 HP 3 PH. 15 HP 3 PH.
Weight (net)
Lbs. Approx.
2600 2600 4250 5800 6200
